Lucent Technologies MERLIN LEGEND Release 6.1 System Planning

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
Issue 1
August 1998
Lines/Trunks
Page 3-64Assigning Telephone Buttons
3
If the system includes a loudspeaker paging system, consider assigning a
programmed Loudspeaker Paging button to DLC positions for one-touch access
to the paging equipment. If the system has fewer than 30 lines, the operator-only
features (Alarm, Night Service, and Send/Remove Messages) are
factory-assigned as shown in Figure 3–6
. The factory assignments can be
changed through centralized telephone programming or by a DLC operator.
Planning Form Instructions 3
Complete the Button Diagram page on each copy of Form 5a and Form 5b:
1. For the Ring and Voice buttons, circle SA or Icom.
2. Write the telephone number of the line/trunk you want to assign in the
space on the Button Diagram page. Record each line/trunk number (see
Form 2c).
3. Assign Alarm, Night Service, or Send/Remove Message buttons by
labeling the appropriate button
Alarm, Nite Svc, or Snd/Rem Msg.
4. Assign programmed Loudspeaker Paging buttons by selecting the button
and writing
Pa g e on it.
Proceed to Chapter 4, “Features,” to complete the remaining sections of these
forms.
