Unit Load Calculation
Page F-3Unit Load Worksheet
F
Unit Load Worksheet F
1. Number of modules in carrier (excluding power supply
and processor):
__________________
■ If fewer than 5, no further calculation is required.
■ If 5 or 6, continue to Step 2.
2. Key or Behind Switch mode only:
Indicate the configuration of lines; then go to Step 5.
 Key
 Modified
3. Hybrid/PBX mode only:
Do all modules in the carrier have MLX and/or
analog multiline telephone jacks?
■ If no, no further calculation is required.
■ If yes, continue to Step 4.
 Yes
 No
4. Hybrid/PBX mode only:
Calculate the total number of MLX and analog
multiline telephones.
Number of MLX-20L telephones connected to
modules in the carrier:
__________________
Number of MLX-28D telephones connected to
modules in the carrier:
__________________
Number of 34-button analog multiline telephones
connected to modules in the carrier:
__________________
Total of MLX-20L, MLX-28D, and 34-button analog
telephones
__________________
■ If the total is less than 45, no further calculation is
required.
■ If the total is 45 or more, continue to Step 5.
