Lucent Technologies MERLIN LEGEND Release 6.1 System Planning

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
Issue 1
August 1998
Control Unit Configuration
Page 2-7Recording System Operating Conditions
2
Recording System Operating
Conditions 2
This section contains instructions for recording the following system operating
conditions:
■ Programming equipment to be used and its extension jack assignment
■ Mode of operation
■ Language choice
■ Enable and disable Automatic Maintenance Busy
■ A reminder to set the system date
■ Backup schedule
■ Identifying system console extensions
■ Second Dial Tone Timer
■ Identifying system applications
Forms Needed 2
Form 1, System Planning
Programming Equipment 2
Two types of equipment can be used for system programming:
■ An MLX-20L telephone identified as a system programming console. The
telephone is connected to the first (lowest) extension jack (which is
factory-set for system programming) on the first MLX module.
■ A personal computer with System Programming and Maintenance (SPM)
software. The PC connects to the lowest jack on the processor module.
Planning Form Instructions 2
1. Under the Programming Equipment heading in the System Operating
Conditions section on Form 1 (page 2), do
one of the following:
■ If the system will use a system programming console, check the
System Programming Console box.
■ If the system will use a PC with SPM software, check the PC with
SPM Software box.
NOTES:
1. In conjunction with the MLX-20L telephone and the PC, a PCMCIA card is
required for Release 3.0 and later of the communications system. Check
the box labeled PCMCIA Memory Card.
2. The first (lowest) extension jack on the first MLX module is factory-set for
system programming and as the primary operator position. Since the
primary operator position cannot be reassigned, you may want to change
the system programming assignment to ensure that future programming
sessions do not interfere with the operator’s work.
