Lucent Technologies MERLIN LEGEND Release 6.1 System Planning

MERLIN LEGEND
®
Communications System Release 6.1
Form 5a
Form 5a-1
Direct-Line Console (DLC): Analog
(Make a copy of this form for each telephone.)
Logical ID _______________ Extension No. _______________ Person or Location _____________________
❑ Copied from Master Ext. No. _________________
Personal Lines
______ ______ ______ ______
______ ______ ______ ______
Auto Line Selection
______ ______ ______ ______
______ ______ ______ ______
Optional Features
Abbreviated Ring
❑ Off
❑ On ✦
Auto Callback
❑ Off ✦
❑ On
Call Waiting
❑ Off ✦
❑ On
Voice-Announced Calls
❑ On ✦
❑ Off
Coverage Inside
❑ Off
❑ On ✦
Cover Ring Delay
Primary Cover Ring Delay
❑ 2 Rings ✦
❑ ____rings (1–6)
Secondary Cover Ring Delay
❑ 2 Rings ✦
❑ ____rings (1–6)
Group Coverage Ring Delay
❑ 3 Rings ✦
❑ ____rings (1–9)
✦ Factory Setting
Extension Jack Pair
❑ Voice Announce to Busy (voice/voice)
❑ Simultaneous Voice and Data (voice/data)
Even-numbered jack
Logical ID _________ Ext. No. __________
Console Model
❑ MERLIN II System Display Console
❑ BIS-34D
❑ BIS-34
❑ BIS-22D
❑ BIS-22
Adjuncts
❑ General Purpose Adapter
❑ FAX machine
❑ Answering machine
❑ Data terminal
❑ Other __________________________
❑ Supplemental Station Alert Adapter
Alert Device type ___________________
❑ Headset
❑ Headset adapter
❑ Hearing-impaired handset
❑ Noisy environment
❑ CTI PC (DLC must be a BIS set)
❑ Other _____________________________
