Lucent Technologies MERLIN LEGEND Release 6.1 System Planning

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
Issue 1
August 1998
Data Communications
Page 5-14About Data and Video Communications
5
Summary of Data Station Configurations 5
Table 5–1 describes the extension jacks and equipment required for each data
station configuration.
Table 5–1. Data Station Configurations
* An analog telephone may be connected.
† A digital data/video station that connects directly to an MLX port using either a BRI interface
or a v.35 interface and an ISDN terminal adapter that supports 2B Data, requires only one
MLX port programmed as a 2B Data port. A digital data/video station that connects to an
MLX port using a v.35 interface and an ISDN terminal adapter that does not support
2B Data, requires two 1B Data MLX ports. When using the 008 MLX or 408 GS/LS-MLX
module for digital data or video, you must
not use Version 29 of the module.
Type of Data
Station
Module and
Jack Type
Telephone
(for voice)
GPA or
MFM
Modem or ISDN
Terminal Adapter
Data
Te rm in al
Analog voice and
Modem data
2 adjacent extension
jacks on one of the
following analog
modules: 408, 408
GS/LS, or 008
Analog multiline
telephone (and a
BR-241-B1 bridging
adapter)
GPA Modem PC
Modem data-only 1 extension jack on
an 008 OPT, 016 T/R
or 012 T/R module
None* None Modem PC, LAN
workstation, or
local host
MLX voice and
Modem data
1 extension jack on
an 008 MLX or 408
GS/LS-MLX module
MLX telephone* MFM Modem PC, or LAN
workstation
MLX voice and
ISDN terminal
adapter data
1 extension jack on
an 008 MLX or 408
GS/LS-MLX module
MLX telephone None ISDN terminal adapter PC, LAN
workstation, local
host, or video
conferencing
ISDN terminal
adapter data-only
1 extension jack on
an 008 MLX or 408
GS/LS-MLX module
None None ISDN terminal adapter
(If using a 7500B data
module, a 440A4
terminating resistor
adapter is also
required)
PC, LAN
workstation, local
host, or video
conferencing
Digital Data/Video 1 extension jack on
an 008 MLX or 408
GS/LS-MLX module
set as a 2B Data port,
or 2 jacks set as 1B
Data ports†
None None None if station is
connected by a BRI
interface. One ISDN
terminal adapter if the
TA supports 2B Data.
Two ISDN terminal
adapters if the TAs
support only 1B Data.
G4 FAX, video
conferencing
