Lucent Technologies MERLIN LEGEND Release 6.1 System Planning

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
Issue 1
August 1998
Unit Load Calculation
Page F-4Unit Load Worksheet
F
5. Calculate the estimated unit loads.
Module Qty x
Unit
Load
= Total
008 12.0
008 MLX 13.25
008 OPT 8.0
012 T/R 8.4
016 T/R 12.8
100D 0.0
400 LS 0.0
400 EM 8.0
400 GS/LS/TTR 0.0
408 12.0
408 GS/LS 12.0
408 GS/LS-MLX 13.5
800 0.0
800 GS/LS 0.0
800 DID 8.0
800 GS/LS-ID 8.0
MERLIN LEGEND Mail 0.0
Total Estimated Unit Load
■ If the total is less than 75 (for the 391C1 or 391A3 power supplies) or 54 (for
the 391A1 or 391A2 power supplies), no further calculation is required.
■ If the total is 75 (391C1 or 391A3 power supplies) or 54 (391A1 or 391A2
power supplies) or more, continue to Step 6.
6. Calculate the actual carrier unit load using the table on the next page.
■ If the total actual unit load is less than or equal to 75 (391C1 or 391A3
power supplies) or less than or equal to 54 (391A1 or 391A2 power
supplies), no further calculation is required.
■ If the total actual unit load is more than 75 (391C1 or 391A3 power supplies)
or more than 54 (391A1 or 391A2 power supplies), continue to Step 7.
