Data Communications
Page 5-26Assigning Extension Jacks
5
Video Systems 5
Video systems may connect to an MLX port on the MERLIN LEGEND system
either directly through a BRI interface, or by way of a v.35 interface and an ISDN
terminal adapter.
Assign each video system that is connected directly to the MLX port, or connected
to an ISDN terminal adapter that supports 2B Data, to one digital jack configured
as a 2B Data port on an 008 MLX or 408 GS/LS-MLX module.
Assign each video system that is connected to an MLX port by way of an ISDN
terminal adapter that does not support 2B Data to two separate digital jacks
configured as 1B Data ports on an 008 MLX or 408 GS/LS-MLX module.
Planning Form Instructions 5
Record the extension jack assignments for video systems on Form 2a, System
Numbering: Extension Jacks.
1. In the Jack Type column, make sure there is a D next to the number for
each digital extension.
2. In the Person, Location, or Function column, enter the type of equipment
connected.
