3
MERLIN LEGEND R6 DESIGN IMPLEMENTATION GUIDE (CONTINUED)
Customer Name: __________________________________ Node: ________
Dial Plan information:
Dial plan numbers for extensions, adjuncts, lines and calling groups must be unique
across the network. Numbers will have to be changed if a conflict is encountered.
MERLIN LEGEND routes Non-Local UDP calls by matching number ranges entered
into the Non-Local UDP tables. These number ranges can consist of 2- to 4-digit
numbers. 4-digit dial plans are recommended for MERLIN LEGEND. If a
DEFINITY is in the network, and has a 5-digit dial plan, MERLIN LEGEND routes
the call on 4-digits, but will send 5 digits.
Pool numbers and line numbers will be made unique across the network. This will be
transparent to the customer.
- What extension range is desired for this location: ________________
(any additional extension ranges?) ________________
(does this range allow for growth?) ________________
________________
- What adjunct range is desired for this location: ________________
(any additional extension ranges?) ________________
(does this range allow for growth?) ________________
Automatic Route Selection (ARS):
• It is strongly recommended that each system in the network have at least 1 local CO
line for emergency use (i.e. 911 calls, power failure use, etc.).
• Traffic must be considered when routing ARS calls across the network, to assure
that enough lines are available to handle call volume.
- ARS access code ____ The same ARS access code is recommended on all systems.
- Will ARS be used to access the facilities on another system on the network for
making local calls _______ ? long distance calls _______ ?
- Will other systems on the network being using this systems ARS for making
local calls _______ ? long distance calls _______ ?
- Have ARS tables been administered, or are only the default tables used?
Default only? _____ Other tables are used. _____
NOTE: There are additional engineering charges when Design Center engineers the
custom ARS tables (1–16), i.e. TEHO. Consult with the assigned engineer.
