Lucent Technologies MERLIN LEGEND Release 6.1 System Planning

MERLIN LEGENDCommunications System Release 6.1
System Planning 555-661-112
Issue 1
August 1998
Lines/Trunks
Page 3-3Identifying Line/Trunk Jacks
3
Table 3–1. Line/Trunk Jack Types
NOTES:
1. You cannot mix T1 and Primary Rate Interface (PRI) service on the same
100D module. Any of the following AT&T Switched Network (ASN)
Services can be provided through a T1 or PRI facility: Megacom

WATS,
Megacom 800, Software Defined Network (SDN), and MultiQuest

. PRI
also supports Call-by-Call Service Selection and some ACCUNET

switched digital services. T1 supports Shared Access for Switched
Services (SASS) and ACCUNET Switched Digital Service (or other
circuit-switched data service) at 56-kbps. Both support Dialed Number
Identification Service (DNIS).
2. The MERLIN LEGEND Communications System supports Centrex
service with loop-start lines only. The system does
not support a timed
switchhook flash with ground-start trunks or ground-start emulation on
DS1 facilities in any mode of operation (Hybrid/PBX, Key, or Behind
Switch).
Module Type
Line/Trunk
Jack Type
Number of
Jacks Used to Connect
400
800
408
Loop-start (LS) 4
8
4
Line/Trunk Types: Basic,
Special Purpose (FX, WATS)
Auxiliary Equipment: Music On Hold,
Loudspeaker paging system,
Maintenance Alarm, MERLIN
Identifier
400 GS/LS
800 GS/LS
408 GS/LS
408 GS/LS-MLX
800 GS/LS-ID
Ground-start/
loop-start
(GS/LS)
4
8
4
4
8
Line/Trunk Types: Basic,
Special Purpose (FX, WATS)
Auxiliary Equipment: Music On Hold,
Loudspeaker paging system,
Maintenance Alarm, MERLIN
Identifier
800 DID
(Hybrid/PBX)
DID 8 DID
800 NI-BRI NI-1 BRI 8 (16 channels) NI-1 BRI
400EM Tie 4 Tie
100D DS1 1 (24 channels) T1
T1 Switched 56 Data
PRI
