Model 3030 & 3030E Series Technical Manual Section 9
Ludlum Measurements, Inc. Page 48 November 2017
Reference Description Part Number
C25 47pF, 100V 04-5660
C26 0.01uF, 50V 04-5664
C27 47pF, 100V 04-5660
C28 100pF, 3KV 04-5532
C29 0.0047uF, 3KV 04-5547
C30 0.1uF, 50V 04-5663
C31-C33 0.02uF, 1KV 04-5651
C34 0.02uF, 3KV 04-5704
C35-C36 0.0047uF, 3KV 04-5547
C37 100pF, 3KV 04-5532
C38 1uF, 35V 04-5656
C39 68uF, 6.3V 04-5654
C40 47uF, 10V 04-5666
C41-C42 0.1uF, 50V 04-5663
Q1 2N7002L 05-5840
Q2 MJD210RL 05-5843
Q3 2N7002L 05-5840
Q4 MJD210RL 05-5843
Q5 MMBT3904LT1 05-5841
U1 MAX232D 06-6382
U2 MAX810LEUR 06-6424
U3 PCF8593TD 06-6403
U4 N87C51FC 06-6303
U5-U6 24C65ISM 06-6401
U7 LM285MX-2.5 06-6291
U8 LTC1257IS8 06-6377
U9 CD74HC4538M 06-6297
U10 TLC372ID 06-6290
U11 CA3096M 06-6288
U12 TLC372ID 06-6290
U13 CD74HC4538M 06-6297
U14 TLC27M7ID 06-6292
CR1-CR4 MMBD914LT1 07-6353
CR5 MMBD7000LT1 07-6355
CR6 MMBD914LT1 07-6353
CR7-CR11 GI250-2 07-6266
TRANSISTORS
INTEGRATED
CIRCUITS
DIODES
