Model 3030 & 3030E Series Technical Manual Section 9
Ludlum Measurements, Inc. Page 51 November 2017
Reference Description Part Number
BOARD Completely Assembled
Power Supply Board 5337-133
C1 2200uF, 50V 04-5724
C2-C3 47uF, 10V 04-5666
C4 22uF, 10V 04-5672
VR1 DDPAK5 05-5885
U1 LT1776 06-6512
U2 LT1304CS8 06-6394
CR1 BRIDGE RECT. DF02S 07-6374
CR2-CR4 RECTIFIER CMSH1-40M 07-6411
CR7-CR11 GI250-2 07-6266
R1-R2 100K 1/8W, 1% 12-7834
R3 33.2K, 1/8W, 1% 12-7842
R4 10K, 1/8W, 1% 12-7839
R5-R6 22.1K, 1/8W, 1% 12-7843
R7 37.4K, 1/8W, 1% 12-7035
R8 12.1K, 1/8W, 1% 12-7879
R9 1.5K, 1/8W, 1% 12-7878
R10 37.4K, 1/8W, 1% 12-7035
R11 5 OHM, 3W, 5% 12-7718
R12 4.75K, 1/8W, 1% 12-7858
R13 100K, 1/8W, 1% 12-7834
R14 37.4K, 1/8W, 1% 12-7035
P7 MTA100 640456-3 13-8081
P8 MTA156 640445-3 13-8125
P9 MTA100 640456-2 13-8073
L1 100uH DT3316 21-9875
L2 22uH CD43 21-9808
S1 ON/OFF
DM62J12S205PQ 08-6715
S2 MICRO FOR TRAY
BZ-2RD-A2 (M3030 only) 08-6538
S111 513384 08-6656
Power Supply Board,
Drawing 337 × 133
CAPACITORS
VOLTAGE
REGULATOR
INTEGRATED
CIRCUITS
DIODES
RESISTORS
CONNECTORS
INDUCTORS
Wiring Diagram,
Drawing 337 × 182
SWITCHES
