27
8.3.7
Streaming Parameter
No
Item
Function Descriptions
1
Resolution
Show or set the R
TSP out
put resolution and fps
2
Bitrate (kbps)
Show or set the R
TSP B
it rate (0 ~ 20000)
3
Port Number
Set the R
TSP port
(
10
0 ~ 10000)
4
Audio Setting
T
urn on/off R
TSP audio
Check to turn on/of
f RSTP audio
5
RTSP
URL
Show current R
TSP URL
connection
6
Save
Click to save settings
7
Cancel
Click to cancel the modified setting
s
1
2
3
4
5
6
7
27
29
