28
8.3.8
Maintenance
No
Item
Function Descriptions
1
Reset to the
default value
Select the reset button to resume t
he factory
default setting as the web
page setting
2
Reboot
Click the reboot button and
reboot the device
3
Error Code
In the event of an error
, an error code log will be
established
4
Clean
If an error code appears, t
he user may try to click
the Clean button to confirm if
the error will repeat
itself.
2
3
1
4
28
30
