29
8.3.9
Maintenance-Upgrade
No
Item
Function Descriptions
1
Current
software
version
Display the current software versio
n of DC-W80
2
Upgrade file path
Click Choose File to select t
he software file to be
updated, and the selected f
ile name will be
displayed after selection
3
Start Update
Click to start upgrade the sof
tware
8.3.10
About
Function Descriptions
Display the related manufacturing inf
ormation of this device,
including device
name, firmware version, M
AC address, serial num
ber
, and others.
1
1
2
3
29
31
