English - 19
Chapter 5 Start Using
<Note>: Ensure that the USB cable is connected and Ladibug™ software is
installed at first. Refer to Chapter 4 Installation and Connections in this user
manual.
1. Double click on icon to begin Ladibug™ Software.
2. Move the mouse to icon, and the main function menu will be displayed.
3. Place an object to be displayed under the camera.
4. Press [PREVIEW]
to display the POWER Frequency setting page, and
then follow the on-screen instructions for setting. The live video will be
available after the setting is completed. (*This setting is required only when
you are using for the first time.)
Note: You are advised to confirm the local voltage/frequency before setting
the POWER Frequency. For example, 60Hz is applicable for America, Taiwan,
Japan, etc; 50Hz is applicable for Europe or other regions.
5. Click button to optimize the image. You are ready to teach/present.
6. Adjust the gooseneck as needed and click [FOCUS] button.
* Each time the camera head is moved, click the [FOCUS] button to refocus the
lens.
