Harmonics of AC voltage in Percentage
* Fundamental frequency 50 Hz, 60 Hz
DW-6195 + CP1201
Range
Resolution
System
Accuracy
1 to 20th
± ( 2 % + 10 d )
21 to 30th 0.1 %
± ( 4 % + 20 d )
31 to 50th
reference
Harmonics of AC current in Magnitude
* Fundamental frequency 50 Hz, 60 Hz
DW-6195 + CP1201
Range
Resolution
System
Accuracy
1 to 20th
± ( 2 % + 0.5 A )
21 to 30th 0.001 A to 1 A
± ( 4 % + 0.5 A )
31 to 50th
reference
Harmonics of AC current in Percentage
* Fundamental frequency 50 Hz, 60 Hz
DW-6195 + CP1201
Range
Resolution
System
Accuracy
1 to 20th
± ( 2 % + 10 d )
21 to 30th 0.1 %
± ( 4 % + 20 d )
31 to 50th
reference
Peak value of ACV or ACA
DW-6195 + CP1201
Range
Resolution
System
Accuracy
ACV ( Peak to Peak ) 0.1 V to 1 V
± ( 5 % + 30 d )
ACA ( Peak to Peak ) 0.001 A to 1 A
