Crest Factor of ACV or ACA
DW-6195 + CP1201
Range
Resolution
System
Accuracy
1.000 - 9.999 0.001
± ( 5 % + 0.3 )
Total Harmonic Distortion
DW-6195 + CP1201
Range
Resolution
System
Accuracy
0 to 20 % 0.1 %
± ( 2 % + 5 d )
20.1 to 100 %
± ( 6 % + 10 d )
3. FRONT PANEL DESCRIPTION
Fig. 1
10
