Lutron Electronics DW-6195 - LOWBAT Screen

5-15 The LOWBAT screen: as show on lower right
display of the following screen.
V12:
0.0 V
V1:
0.0 V
A1:
0.00 A
V23:
0.0 V
V2:
0.0 V
A2:
0.00 A
V31:
0.0 V
V3:
0.0 V
A3:
0.00 A
P1:
-0.000 KW
S1:
0.000 KVA
Q1:
- 0.000 KVAR
P2:
-0.000 KW
S2:
0.000 KVA
Q2:
- 0.000 KVAR
P3:
-0.000 KW
S3:
0.000 KVA
Q3:
- 0.000 KVAR
PΣ :
-0.000 KW
SΣ:
0.000 KVA
QΣ:
- 0.000 KVAR
PF1:
- 0.00
PF2:
- 0.00
PF3:
- 0.00
PFΣ:
0.00
PFH:
0.00
Φ1:
- 0.0°
Φ2:
- 0.0°
Φ3:
- 0.0°
WH:
0.000 KWH
SH:
0.000 KVAH
QH:
0.000 KVARH
FREQ:
0.0 Hz
CP1201 LOWBAT
20A 3Φ4W SEC: 2 CT: 1 PT: 1
R
emark:
* During power on , when battery voltage < 7.0 V , the power analyzer
meter will show as 5-15 The LOWBAT screen .
* During power off ,press power button want to power on the meter,
if the battery voltage < 7.0 V , the power analyzer meter will auto
power off again.
* When the meter is turned on the screen stops and cannot
continue, At this time, please check the battery power,
If not enough 7.0 V, please replace the battery.
