screen 2 ( 4-5-6 )
Folder Name: WTA01
SETUP
File Name: 3P401001.XLS
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delete File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT:
1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep: ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
4-5-7 CT: Set the Current Transformer
A : When press SHIFT KEY once, the symbol " SHIFT1 "
will disappear as screen 2 at this time press ▲ or ▼ can
adjust to expect CT values, the adjusting numbers are
from 1 to 600.
Remark : When press ▲ or ▼ > 2 sec, the setting
no. will change fast.
B : Press SHIFT KEY once again will return to screen 1
then press ▼ to enter next setting function ( CT →
BEEP ).
27
