Lutron Electronics DW-6195 - Page 34

screen 2 ( 4-5-8 )
Folder Name: WTA01
SETUP
File Name: 3P401001.XLS
REC Date: 2017-11-28 00:03:17
Sampling Time: 2 Trans Ref : 220.0 V
Delete File: 0 % SDVP : 10%
SD Format: 0 % Decimal: Basic
Use Size: 388 KB Clamp Type: CP1201
Free Size: 1946 MB A Range: 200A
Total Size: 1946 MB V Range: 200mV
RS232 Out Sel:
PT: 1 : 1 V1 I1 P1
CT: 1 : 1 S1 Q1 PF1
Beep:
ON Φ1 FREQ
Year Month Date Hour Minute Second
2010 11 13 14 37 25
4-5-9 Trans Ref: Nominal voltage for
transient detection reference
A : When press SHIFT KEY once will disappear as screen 2,
at this time press ▲ or ▼ to adjust the voltage level
to 50.0 V to 850.0 V.
B : Press SHIFT KEY once again will return to screen 1 then
press ▼ to enter next setting function ( Trans Ref →
SDVP ).
30
