Step 4
Insert the blade holder into tool carriage. Please note the outward ring of the holder must be placed into the
grooves of carriage fi rmly (see Figure 2-14), then fasten the case (Figure 2-15)
Figure 2-14 Figure 2-15
Step 5
Use the reversing steps to remove the blade holder.
Step 6
Eject the blade. Push “Blade eject pin” to eject blade when the blade needs to be replaced.
Caution
The blade will lose its sharpness after a period of usage, and the cutting quality might be affected. Increasing the
cutting force, might do the trick. However, once the blade is worn out and no longer provides a reliable cutting,
you should replace with a new blade. The blade is a consumable and must be replaced as often as necessary
to maintain the cutting quality. The quality of the blade affects cutting quality. So be sure to use a high quality
blade to ensure good cutting results.
2. Installation 2-8
