Lynx S-30 User Manual

Model Name/ No. LYNX S-60
24” cutter
LYNX S-30
12”cutter
Operational Method Roller-Type
Max. Cutting Width 590mm (23.23in) 280mm (11.02in)
Max. Media Loading Width 719mm (28.3in) 459mm (18.07in)
Min. Media Loading Width 50 mm
Acceptable Material Thickness 0.8mm (0.03 in)
Number of Pinch Rollers 2
Drive DC Servo Control
Cutting Force 0~300 g
Max. Cutting Speed Up to 600 mm/sec (23.62 ips)
Offset 0~1.0 mm
Mechanical Resolution 0.009 mm
Software Resolution 0.025 mm
Distance Accuracy 0.254 mm or 0.1 % of move, whichever is greater
Repeatability + 0.1 mm up to 3 meters (*certifi ed media)
Buffer Size 4 MB
Interfaces Parallel (Centronics) & Serial (RS-232C)
Commands HP-GL, HP-GL/2
Confi gurable Origin Yes
Vector Look Ahead Yes
Curve & Arc Smoothing Yes
Test Cut Possibility Yes
Repeat Function Yes
Control Panel 10 Control Keys, 6 LED
Dimension (HxWxD) mm
(HxWxD) in
220 x 879 x 258
8.67 x 34.61 x 10.16 lb
220 x 619 x 258
8.67x 24.37 x 10.16 in
Net Weight (kg) 13 kg/ 28.6 lb 10.2 kg/ 22.4 lb
Power Supply 115V/230V (manual switch)
Environment Temperature 0
o
C~55
o
C / 32
o
F~131
o
F (operating)
-40
o
C~75
o
F~167
o
F (storage)
Environment Humidity 30% ~ 70% relative humidity (operating)
*This specifi cation is subject to change without prior notice.
Specifi cation: Lynx S-60, S-30
Equipment Specifi cation
A. Equipment Specifi cation V

Lynx S-30 Specifications

General

Brand	Lynx
Model	S-30
Category	Cutter
Language	English
