mabe Kraken - Page 70

Ingeniería de Servicio
- 70 -
Fault Codes
Fault
Code
(Hex)
Name
Description
Repair Action
18
Drain
Pump
Clearing
algorith
m failed.
While draining the
pressure sensor
value for water level
did not indicate the
washer was empty
before the Max
Continuous Drain
ON time was
reached.
 This fault is set and will be seen with fault 16
when Drain Pump Clearing Algorithm failed to
remove the blockage and the rest of water in
tub.
 Check the drain pump for blockage.
 Check installation instructions for proper
standpipe height.
 Check pressure tube for pinches where it
goes through top cover grommet.
 Check pressure tube for trapped water.
 Check the output voltage from the pressure
sensor to ensure it matches the water level in
the basket according to the pressure sensor
chart. If it does not, the control will need to be
replaced as the pressure sensor is mounted
directly to the control.
 Check resistance of the pump (13.2 ohms)
from J512 connector on the control.
 If open circuit, check wiring harness to the
pump and pump motor.
 Check for 120 VAC to the drain pump.
 If voltage is present and pump does not
operate, replace pump.
 If voltage is not present, replace IMC
(Interface Machine Control).
19
UI State
Timeout
Washer was paused
for over 12 hours
 This is normal operation. This will happen if
the consumer and or control switched cycle to
a paused state.
