mabe Kraken - Page 71

Ingeniería de Servicio
- 71 -
Fault Codes
Fault
Code
(Hex)
Name
Description
Repair Action
20
Critical
Flood
Level by
Gallons
Water volume into
the tub exceeded 41
gallons as calculated
by the control.
1. Pressure tube is
momentarily
pinched, has water in
it, partial blockage if
Flood fault 12
occurs.
2. Low water
pressure/flow or
permanent pressure
system blockage if
NO Flood fault 12
occurs.
 Check pressure tube for pinches where it
goes through top cover grommet.
 Check pressure tube for trapped water.
 Check for any leaking water valves.
 Check home water pressure.
 Check the output voltage from the pressure
sensor to ensure it matches the water level in
the basket according to the pressure sensor
chart, if it does not, the control will need to be
replaced as the pressure sensor is mounted
directly to the control.
21
Flood
Warning
Level by
Gallons
Water volume into
the tub exceeded
36.3 gallons as
calculated by the
control. Stops filling.
1. Pressure tube is
momentarily pinched
or has water in it,
partial blockage if
Flood fault 6, 7, or 12
occurs.
2. Low water
pressure/flow or
permanent pressure
system blockage if
NO Flood fault 6, 7,
or 12 occurs.
 Check pressure tube for pinches where it
goes through top cover grommet.
 Check pressure tube for trapped water.
 Check for any leaking water valves.
 Check home water pressure.
 Check the output voltage from the pressure
sensor to ensure it matches the water level in
the basket according to the pressure sensor
chart, if it does not, the control will need to be
replaced as the pressure sensor is mounted
directly to the control.
