mac.pan MD - Wiring Diagram

MADE IN ITALY
25
electric modular oven
MD CAP. 1 PAG. 23
FEATURES TABLE
Electromagnetic environment immunity EN 61000-6-2 and EN 61000-6-4
industrial
Expected short circuit current at the power supply point of the machine
≤10
kA
Power supply earthing connection
TN
Neutral switch-disconnector
n.a.
Max impedance of the earthing connection at the point of installation (TN
systems)
2,15 Ω
Power surge fittings of the machine power supply conductors
Client’s task
Room temperature
+5°C -40°C
°C
Max height
1000
m/slm
Relative humidity
< 50% (T
amb
= 30°C)
< 95% (T
amb
= 25°C)
Max allowed internal over-temperature versus internal temperature of 35°C
10
°C
Electrical cabinet protection level
IP54
Control panel protection level
IP54
Cabling protection level
IP65
Motor protection level
IP54
1.7
Wiring Diagram
see ATTACHMENT “F”
