3.1
Operation checks
Motor rotation
FIG.1
Use the relevant key to start the steam extractor (Pos.1)
Check the correct direction of rotation shown in the figure
If the direction of rotation is incorrect, turn off the machine immediately and correct the direction of
rotation of the motor.
Water Feeding Circuit
FIG.2
Check the water circuit with cold humidifier.
Use the relevant key to enable the water inlet solenoid valve.
The water flow should not be interrupted in any point along its route (see the figure). Remove any
deposits of limescale or other materials.
For all details refer to annex “EC”
