MacDon FFT FlexDraper FD75 - Page 13

214251 7 Revision A
Ref
Part
Number Description Qty
1
279285
HOSE – HYD (SIDE DRAPER RETURN)
1
2 279286
HOSE – HYD (SIDE DRAPER INTERCONNECT, PRESSURE)
1
3 279284
HOSE – HYD (SIDE DRAPER PRESSURE)
1
4
245590
HOSE – HYD (CASE DRAIN)
1
5
NSS
1
PLATE – TRANSITION PAN SEAL 1
6 220936 MOTOR – HYD DANFOSS 2.44 CI 2
7
252211 FITTING – TEE
1
8 252210
FITTING – 90 ° ELBOW
1
9 50104
FITTING – ELBOW 90° HYD
1
10 30981
FITTING – ADAPTER HYD REDUCER 1/2 X 3/8
1
11
252414 FITTING – ADAPTER HYD SWIVEL
1
12 30999
CAP – 3/4 IN. TUBE 37° FLARE
1
13 108233
CAP – 1/2 IN. TUBE (SINGLE KNIFE ONLY)
1
14
21069
NUT – TUBE 37° JIC 1/2 IN.
1
15 NSS
1
NUT – WELD M8 X 1.25-6H
5
16 135443 CINCH STRAP – 4 IN. LG 3
17
40702 FASTENER – CABLE TIE, RED
1
18 NSS
1
PLATE – BLKD FITTING MOUNT
1
PARTS LIST
1. Not Serviced Separately.
