Figure 4.23: Tine Tube Reinforcing Kit Opposite
Support (Option)
33. On each reel, there are two left-facing supports (A). Rotate
the supports until the flanges clear the channels before
moving them off bushing (B). Move the tube slightly away
from the reel if necessary.
34. Remove bushing halves (B) from the tine tubes.
REMOVING EXISTING FINGERS AND BUSHINGS
