INSTALLATION INSTRUCTIONS
Figure 3.42: Cutterbar Door Latch: 16-Ft. SP
2. Hook curtain latches (A).
Fig
ure 3.43: Curtain Latches: 16-Ft. PT
147974 31 Revision B
