INSTALLATION INSTRU CTIONS
3.11.2 Closin
g the C utterbar Doors: Export Header or Mower C onditioner
To close the cutterbar doors on an export header or mower conditioner follow these steps:
CAUTION
To avoid injury, keep hands and fingers away from corners of doors when closing.
1. Pull at top and move to closed position. Ensure
latch (A) has engaged the door.
Figure 3.41: Cutterbar Door Latch: 16-Ft. PT
147974 30 Revision B
