INTRODUCTION
Parts identification
1. Front brake lever and reservoir.
2. Rear brake lever and reservoir.
3. Instrument panel.
4. Secondary battery storage compartment.
5. Rear wheel motor.
6. Front indicator.
7. Front headlight.
8. Front fork.
9. Mirror.
10. Left-hand handlebar controls.
11. Right-hand handlebar controls.
12. Throttle control.
13. Front brake disc.
14. Front brake caliper.
15. Seat.
16. 12-volt battery access panel.
17. Side stand.
18. Reflector.
19. USB-C socket (in the storage compartment).
20. Rear light.
21. Rear indicator.
22. Foot peg.
23. Rear brake disc.
24. Rear brake caliper.
25. Rear shock absorber.
26. Primary battery compartment.
1 2
8
6
7
18
19
9
20
21
121110 15 18
22 23
24
25 26
14 16 1713
3 4 5
