MagCore® Plus II
PLC Configuration
I/O IN I/O OUT
X0 Y Motor Encoder Signal(A) Y0 Y Motor Drive(A)
X1 Y Motor Encoder Signal(B) Yl Y Motor Drive(B)
X2 Y Home Sensor Signal Y2 V Motor Drive(A)
X3 Y3 V Motor Drive(B)
X4 V Motor Encoder Signal A Y4 X Motor Drive(A)
X5 V Motor Encoder Signal B Y5 X Motor Drive(B)
X6 V Home Sensor Signal Y6
X7 UP Sensor Signal Y7
X8 Y8
X9 Y9
X10 X Motor Encoder Signal(A) Y10 M DC Motor JOG
X11 X Motor Encoder Signal(B) Y11 UV Lamp Switch-Relay
X12 X Home Sensor Signal Y12 RS232 Switch
X13 Down Sensor Signal
X14
X15
X16
X17 Door Sensor
