2.3.3 Memory Configuration

There is no jumper setting required for the memory size or type. It is

automatically detected by the system BIOS, and the total memory size is to add

them together.

DIMM Socket DIMM Modules

DIMM1

EDO/SDRAM 8, 16, 32, 64, 128MB

DIMM2

EDO/SDRAM 8, 16, 32, 64, 128MB

DIMM3

EDO/SDRAM 8, 16, 32, 64, 128MB

The S7-MVP3 Motherboard has been tested with the memory listed below.

Size/Type Vendor Model Side Chip

Count

SPD

16MB/SDRAM Fujitsu 811171622A-100FN x2 8 No

16MB/SDRAM Hitachi HM5216805TT10 x1 8 No

16MB/SDRAM HY57V168010BTC-10 X1 8 Yes

32MB/SDRAM Mitsubishi M5M4V16S30BTP-10 x2 16 No

32MB/SDRAM Mitsubishi M5M4V16S30BTP-10 x2 16 Yes

32MB/SDRAM OKI M56V16800D-10 X2 16 No

32MB/SDRAM HY57V168010BTC-10 x2 16 Yes

32MB/SDRAM TI TMS626812DGE-12A x2 16 No

32MB/SDRAM Micronic MT48LC2M8A1-12 x2 16 No

64MB/EDO Panasonic MN41V17400CTT-06 X2 32 No

128MB/SDRAM NEC D4564841G5-A10-9JF x2 16 No

2.4 I/O Connections/Panel Connections

I/O Connections

CN1 ATX Power Connector

JIR1, IR IrDA Connector ( Cable optional )

FDD1 Floppy Disk Drive Connector

IDE1, 2 Primary/ Secondary IDE Connectors

PS2, J2 PS/2 Mouse Port

KB, J1 Keyboard Connector

COM1,2 Serial Ports 1 & 2

LPT1 Printer Port

JUSB1 USB Connector
