3.7.9 IR Function Duplex (Half)
This item allows you to select the IR function when you select the UART
2 Mode is ASKIR
3.7.10 RxD , TxD Active (Hi,Hi)
This item allows you to determine the active of RxD, TxD.
3.7.11 Onboard Parallel Port (378/IRQ7)
This item allows you to determine access onboard parallel port controller
with which I/O address.
3.7.12 Onboard Parallel Mode (ECP/EPP)
Select an operating mode for the onboard parallel (printer) port. Normal
EPP (Extended Parallel Port) ECP (Extended Capabilities Port)
ECP+EPP PC AT parallel port Bi-directional port Fast, buffered port
Fast, buffered, bi-directional port.
Select Normal unless you are certain your hardware and software both
support EPP or ECP mode.
3.7.13 ECP Mode Use DMA (3)
Select a DMA channel for the parallel port for use during ECP mode.
3.7.14 Parallel Port EPP Type (EPP1.9)
This item allows you to determine the EPP Type of onboard I/O chip.
3.8 Load BIOS Defaults
This loads the standard BIOS default values. To select, highlight it and press
the¡ÕEnter¡Ö key. Then press the ¡ÕY¡Ö and ¡ÕEnter¡Ö keys to
confirm. Otherwise, press the ¡ÕN¡Ö key to cancel.
3.9 Load Setup Defaults
