3.7 Integrated Peripherals
You can control Input and Output functions from this manual.
Figure 3-7 Integrated Peripherals
ROM PCI / ISA BIOS (2A5LEV5B)
INTEGRATED PERIPHERALS
AWARD SOFTWARE, INC.
OnChip IDE First Channel : Enabled Onboard Parallel Mode : ECP/EPP
OnChip IDE Second Channel : Enabled ECP Mode Use DMA : 3
IDE Prefetch Mode : Enabled Parallel Port EPP Type : EPP1.9
IDE HDD Block Mode : Enabled
IDE Primary Master PIO : Auto
IDE Primary Slave PIO : Auto
IDE Secondary Master PIO : Auto
IDE Secondary Slave PIO : Auto
IDE Primary Master UDMA : Auto
IDE Primary Slave UDMA : Auto
IDE Secondary Master UDMA : Auto
IDE Secondary Slave UDMA : Auto
Onboard FDC Controller : Enabled
ESC : Quit ↑ ↓ → ←: Select
Item
Onboard Serial Port 1 : 3F8/IRQ4 F1 : Help PU/PD/+/- : Modify
Onboard Serial Port 2 : 2F8/IRQ3 F5 : Old Values (Shift) F2 : Color
UART 2 Mode : Standard F6 : Load BIOS Defaults
Onboard Parallel Port : 378H/IRQ7
F7 : Load Setup Defaults
3.7.1 OnChip IDE First/Second Channel (Enabled)
This chipset contains a PCI IDE interface with support for two IDE
channels. Select Enabled to activate the first and/or second IDE interface.
Select Disabled to deactivate this interface, if you install a first and/or
second add-in IDE interface IDE interface.
3.7.2 IDE Prefetch Mode (Enabled)
Enable prefetching for IDE drive interfaces that support its faster drive
accesses. If you are getting disk drive errors, change the setting to omit the
drive interface where the errors occur. Depending on the configuration of
your IDE subsystem, this field may not appear, and it does not appear
when the Internal PCI/IDE field, above, is Disabled.
