3.6 PNP/PCI Configuration Setup
This section describes configuring the PCI bus system. PCI, or Personal
Computer Interconnect, is a system which allows I/O devices to operate at
speeds nearing the speed the CPU itself uses when communicating with its own
special components. This section covers some very technical items and it is
strongly recommended that only experienced users should make any changes to
the default settings.
Figure 3.6 PNP/PCI CONFIGURATION SETUP
ROM PCI / ISA BIOS (2A5LEV5B)
PNP/PCI CONFIGURATION
AWARD SOFTWARE, INC.
PNP OS Installed : No CPU to PCI Write Buffer : Enabled
Resources Controlled By : Manual
PCI Dynamic Bursting : Enabled
Reset Configuration Date : Disabled PCI Master 0 WS Write : Enabled
ACPI I/O Device Node : Enabled PCI Delay Transaction : Enabled
IRQ-3 assigned to : Legacy ISA PCI Master Read Prefetch : Enabled
IRQ-4 assigned to : Legacy ISA PCI#2 Access #1 Retry : Disabled
IRQ-5 assigned to : PCI/ISA PnP AGP Master 1 WS Write : Enabled
IRQ-7 assigned to : Legacy ISA AGP Master 1 WS Read : Disabled
IRQ-9 assigned to : PCI/ISA PnP
IRQ-10 assigned to : PCI/ISA PnP PCI IRQ Actived By : Level
IRQ-11 assigned to : PCI/ISA PnP Assign IRQ For USB : Disabled
IRQ-12 assigned to : PCI/ISA PnP Assign IRQ For VGA : Enabled
IRQ-14 assigned to : Legacy ISA
IRQ-15 assigned to : Legacy ISA
DMA-0 assigned to : PCI/ISA PnP
ESC : Quit ↑ ↓ → ←: Select Item
DMA-1 assigned to : PCI/ISA PnP F1 : Help PU/PD/+/- : Modify
DMA-3 assigned to : PCI/ISA PnP F5 : Old Values (Shift) F2 : Color
DMA-5 assigned to : PCI/ISA PnP F6 : Load BIOS Defaults
DMA-6 assigned to
DMA-7 assigned to
: PCI/ISA PnP
: PCI/ISA PnP
F7 : Load Setup Defaults
3.6.1 PNP OS Installed (Yes)
Select Yes if the system operating environment is Plug-and-Play aware
(e.g., Windows 95).
3.6.2 Resources Controlled By (Auto)
Default setting is "Auto". This setting allows the BIOS to automatically
configure all of the boot and Plug and Play compatible devices. However,
this capability means absolutely nothing unless you are using a Plug and
lay operating system such as Windows95. The user can select and
configure IRQs under "Manual" mode.
3.6.3 Reset Configuration Date (Disabled)
Normally, you leave this field Disabled. Select Enabled to reset Extended
System Configuration Data (ESCD) when you exit Setup if you have
