Magiglo Solitaire - Physical Barrier

Page 27
3.5.2. Physical Barrier
Any physical barrier should meet the
following requirements:
1. Provide at least the equivalent level of
warning to the approach of an open fire,
to that of a hearth.
2. Define a clear zone where occupants
must exercise additional caution.
3. Should be constructed of non-
combustible material, of robust design
and fixed in such a way so as to provide
a secure boundary and be mechanically
fixed to prevent accidental and/or
unintentional removal.
Such a device could take the form of a
fender, a shelf, a wall mounted decorative
bar, etc.
All Solitaire Models
W Must project a minimum of
150mm either side of any naked
flame or incandescent material
D Must project a minimum of
300mm in front of any naked
flame or incandescent material
The height of any physical barrier must
be a minimum of 50mm above the
finished floor level.
Table 2 – Protected Area
Figure 34 and Figure 35 show examples of
area to be protected by the physical barrier.
Figure 36, Figure 37 and Figure 38 show
methods for calculating the barrier width, but
must remain at least the width of the
fireplace opening.
W
D
F
i
r
e
b
e
d
Figure 34
D
F
i
r
e
b
e
d
Figure 35
Fire Bed
XX
Y
X=150mm, less dimension Y
Figure 36
Fire Bed
XX
Y
X=150mm, less dimension Y
Figure 37
Fire Bed
XX
X=150mm
Figure 38
