Page 28
Figure 39, Figure 40, Figure 41 and Figure 42 show examples of how the requirements for
the physical barrier may be met.
D
W
Figure 39 – Example of physical barrier
(dimensions as stated in Table 2 – Protected Area)
D
W
Figure 40 – Example of physical barrier
(dimensions as stated in Table 2 – Protected Area)
D
W
50mm
Min
Figure 41 – Example of physical barrier
(dimensions as stated in Table 2 – Protected Area)
W
D
Figure 42– Example of physical barrier
(dimensions as stated in Table 2 – Protected Area)
