(14) Comparator threshold setting command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x11
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※Code
Frame number
Setting value (Hex)
‘A’～’J’
0x30～0x39
‘K’～’P’
0x41～0x46
5
DATA2
※ASCII code
Comparator group number
Setting value (Hex)
‘1’
0x31
‘2’
0x32
‘3’
0x33
‘4’
0x34
‘5’
0x35
‘6’
0x36
‘7’
0x37
‘8’
0x38
6
DATA3
※ASCII code
Comparator step number
Setting value (Hex)
‘1’
0x31
‘2’
0x32
‘3’
0x33
‘4’
0x34
7
～
10
DATA4
～
DATA7
Comparator threshold
※4 Byte 8 digit integer (Hex)
(Example)
＋0.1μm → ＋1 (0x01)
－0.1μm → －1 (0xFFFFFFFF)
＋12.3456mm → ＋123456 (0x19C53)
－12.3456mm → －123456 (0xFFFE1DC0)
11～15
DATA8
～
DATA11
Dummy
0x00
