47
(15) Comparator threshold acquisition command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x12
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※Code
Frame number
Setting value (Hex)
‘A’～’J’
0x30～0x39
‘K’～’P’
0x41～0x46
5
DATA2
※ASCII code
Comparator group number
Setting value (Hex)
‘1’
0x31
‘2’
0x32
‘3’
0x33
‘4’
0x34
‘5’
0x35
‘6’
0x36
‘7’
0x37
‘8’
0x38
6
DATA3
※ASCII code
Comparator step number
Setting value (Hex)
‘1’
0x31
‘2’
0x32
‘3’
0x33
‘4’
0x34
7～15
DATA4
～
DATA11
Dummy
0x00
