48
(16) I/O function assignment setting command
Offset
Label
Setting value (Hex)
0
INC
Enter an arbitrary value different from the value previously sent.
1
CMD
0x13
2
RSV1
0x00
3
RSV2
0x00
4
DATA1
※ASCII code
Target I / O
module number
Setting value (Hex)
‘0’：IO1
0x30
‘1’：IO2
0x31
5
DATA2
※ASCII code
Type
Setting value (Hex)
‘I’：Input
0x49
‘O’：Output
0x4F
6
DATA3
※ASCII code
Terminal number
Setting value (Hex)
‘0’
0x30
‘1’
0x31
‘2’
0x32
‘3’
0x33
‘4’
0x34
‘5’
0x35
‘6’
0x36
‘7’
0x37
7
DATA4
※ASCII code
Input function
Setting value (Hex)
‘0’：Addr0
0x30
‘1’：Addr1
0x31
‘2’：Addr2
0x32
‘3’：Addr3
0x33
‘4’：Dreq
0x34
‘5’：Comp0
0x35
‘6’：Comp1
0x36
‘7’：Comp2
0x37
‘8’：Reset
0x38
‘9’：Preset
0x39
‘A’：Reset_org
0x41
‘B’：Mode0
0x42
‘C’：Mode1
0x43
‘D’：Start
0x44
‘E’：Pause
0x45
‘X’：No_Func
0x58
