57-645 Eclipse Guided Wave Radar Transmitter - PROFIBUS PA
™
6.0 Diagnostic Parameters
The Eclipse Model 705 measurement engine runs through a
series of self-tests and will detect and report faulty opera-
tion. The TRANSDUCER BLOCK displays these faults in
the DEVICE_STATUS parameter. Refer to Section 7.1.2
for more information on specific faults and warnings.
When the Model 705 transmitter is initially powered on,
the measurement engine does not have enough valid meas-
urement cycles to make a decision about the output level.
For the first sixteen measurement cycles after power is
applied, the QUALITY is “Uncertain,” the SUB_STATUS
is “Initial value,” and the LIMIT attribute is “Constant.”
ElecTemp
xxx C
None
Diagnostic Display
Present temperature in electronics
compartment (degrees Celsius)
Max Temp
xxx C
Superuser
Diagnostic Display
Maximum electronics
temperature recorded
Min Temp
xxx C
Superuser
Diagnostic Display
Minimum electronics
temperature recorded
SZ Hyst
xx.x su
Superuser
Superuser Parameter Safety Zone hysteresis height
Compsate
Superuser
Superuser Parameter
Select from None,
Manual, Auto
DrateFct
xxxx
N
one
Diagnostic Display
Compsate = Auto, velocity
derating factor
TargAmpl
xxxx
None
Diagnostic Display
Compsate = Auto, target
n
egative threshold amplitude
Targ Tks
xxxx
None
Diagnostic Display
Compsate = Auto, measured time of flight
from fiducial to target
Targ Cal
xxxx
S
uperuser
Diagnostic Display
Compsate = Auto, calibrated time of flight
from fiducial to target in room temperature air
OperMode
(select)
Superuser
Superuser Parameter
Compsate =
Auto, select from Run, Cal, Off
7xK Corr
xxx
Superuser
Superuser Parameter
Probe Model = 7xK, Distance in mm from
fiducial to user reference point
Snsr Val
xxx.x su
None
Distance to the target relative to the sensor
reference point.
SnrCalLo
xxx.x su
Superuser
The lower calibrated point of Sensor Value.
It refers to PrLvl Lo.
In Sensor Units. Set to entered Probe
Ln
SnrCalHi
xxx.x su
Superuser
The higher calibrated point of Sensor
Value. It refers to PrLvl Hi.
In Sensor Units
ProbeLvl
xxx.x plu
None
Level on the probe relative to the end of
the probe.
PrLvl Lo
xxx.x plu
Superuser
Value of PrLvl at SnrCalLo. In Probe Level Units
PrLvl Hi
xxx.x plu
Superuser
Value of PrLvl at SnrCalHi. In Probe Level Units
