Appendix – Transducer Block Parameters
49
57-645 Eclipse Guided Wave Radar Transmitter - PROFIBUS PA
™
  
0 BLOCK_OBJECT BLOCK OBJECT
1 ST_REV ST REV
2 T
AG_DESC
T
AG DESC
3 STRATEGY STRATEGY
4 ALERT_KEY ALERT KEY
5 TARGET_MODE TARGET MODE
6 MODE_BLK (Act, Perm, Norm) MODE BLK
7 ALARM_SUM ALARM SUM
8 LEVEL Level
9 LEVEL_UNIT Level Unit
10 PROBE_LEVEL Probe Level
11 PROBE_LEVEL_UNIT Probe Level Unit
12 SENSOR_VALUE Sensor Value
13 SENSOR_UNIT Sensor Unit
18 SENSOR_OFFSET Sensor Offset
19 CAL_TYPE Calibration Type
20 CAL_POINT_LO Sensor Cal Lo
21 CAL_POINT_HI Sensor Cal Hi
22 PROBE_LEVEL_LO Probe Level Lo
23 PROBE_LEVEL_HI Probe Level Hi
24 LEVEL_OFFSET Level Offset
25 LIN_TYPE Lin Type
28 SENSOR_HIGH_LIMIT Sensor High Limit
29 SENSOR_LOW_LIMIT Sensor Low Limit
53 PROBE_MODEL Probe Model
54 PROBE_MOUNT Probe Mount
55 MEASUREMENT_TYPE Measurement Type
56 PROBE_LENGTH Probe Length
57 DIELECTRIC_RANGE Dielectric Range
58 SENSITIVITY Sensitivity
59 BLOCKING_DISTANCE Blocking Distance
60 SAFETY_ZONE_MODE Safety Zone Mode
61 SAFETY_ZONE_HEIGHT SZ Height
62 SZ_LATCH_RESET SZ Latch Reset
63 THRESHOLD Threshold
64 TRIM_LEVEL Trim Level
65 VOLUME Volume
66 VOLUME_UNIT Volume Unit
67 INTERFACE Ifc Level
68 INTERFACE_UNIT Ifc Level Unit
69 UPPER_LIQUID_DIELECT Upper Dielectric
70 INTERFACE_THRESHOLD Interface Threshold
71 INTERFACE_VOLUME Ifc Volume
72 INTERFACE_VOL_UNIT Ifc Volume Unit
73 STRAP_TABLE_LENGTH Strapping Table Length
74 TABLE_VOLUME_UNIT Table Volume Unit
75 STRAPPING_TABLE_PT01 StrappingTbl Pt01
76 STRAPPING_TABLE_PT02 StrappingTbl Pt02
77 STRAPPING_TABLE_PT03 StrappingTbl Pt03
78 STRAPPING_TABLE_PT04 StrappingTbl Pt04
79 STRAPPING_TABLE_PT05 StrappingTbl Pt05
80 STRAPPING_TABLE_PT06 StrappingTbl Pt06
81 STRAPPING_TABLE_PT07 StrappingTbl Pt07
82 STRAPPING_TABLE_PT08 StrappingTbl Pt08
83 STRAPPING_TABLE_PT09 StrappingTbl Pt09
84
STRAPPING_TABLE_PT10
StrappingTbl Pt10
85
STRAPPING_TABLE_PT11
StrappingTbl Pt11
  
86 STRAPPING_TABLE_PT12 StrappingTbl Pt12
87 STRAPPING_TABLE_PT13 StrappingTbl Pt13
88 STRAPPING_TABLE_PT14 StrappingTbl Pt14
89 STRAPPING_TABLE_PT15 StrappingTbl Pt15
9
0
STRAPPING_TABLE_PT16 S
trappingTbl Pt16
91 STRAPPING_TABLE_PT17 StrappingTbl Pt17
92 S
TRAPPING_TABLE_PT18
StrappingTbl Pt18
93 STRAPPING_TABLE_PT19 StrappingTbl Pt19
94 STRAPPING_TABLE_PT20 StrappingTbl Pt20
95 FID_TICKS Fiducial Ticks
96 FID_SPREAD Fiducial Spread
97 LEVEL_TICKS Level Ticks
98 INTERFACE_TICKS Interface Ticks
99 INTERFACE_MEDIUM Interface Medium
100 ENTER_PASSWORD Enter Password
101 NEW_PASSWORD New User Password
102 DEVICE_STATUS Device Status
103 HISTORY_MESSAGE History Message
104 HISTORY_CONTROL History Control
105 RESET_HISTORY Reset History
106 FID_TYPE Fiducial Type
107 FID_GAIN Fiducial Gain
108 WINDOW_705 Window
109 CONVERSION_FACTOR Conversion Factor
110 SCALE_OFFSET Scale Offset
111 NEGATIVE_AMPLITUDE NegThreshold Ampl
112 INTERFACE_AMPLITUDE IfcThreshold Ampl
113 POSITIVE_AMPLITUDE PosThreshold Ampl
114 SIGNAL Signal Strength
115 COMPENSATION Compensation Mode
116 DERATE_FACTOR Derating Factor
117 TARGET_AMPLITUDE Target Amplitude
118 TARGET_TICKS Target Ticks
119 TARGET_CAL Targ Calib Value
120 TARGET_OPER_MODE Target OperMode
121 SEVENXK_DIST_CORRECT 7XK Correction
122 ELECT_TEMPERATURE Elec Temperature
123 MAX_ELECTRONICS_TEMP Max Temperature
124 MIN_ELECTRONICS_TEMP Min Temperature
125 RESET_ELECT_TEMP Reset Temperature
126 SZ_HYSTERESIS SZ Hysteresis
127 LCD_LANGUAGE LCD Language
128 STEAM_CAL_MOUNT Steam Cal Mount
129 RAMP_SLOPE Ramp Slope
130 BASE_FID_TICKS Base Fid Ticks
131 FACTORY_PARAM_1 Factory Param 1
132 FACTORY_PARAM_2 Factory Param 2
133 ECHO_SUMMARY Echo Summary
134 ECHO_DATA Echo Data
135 ECHO_DATA_INDEX EchoData Indx
136 NON_VOL_STAT Non Vol Stat
137 DATE_CODE Date Code
138 MAGNETROL_SERIAL_NUM Magnetrol S/N
139 FIRMWARE_VERSION Firmware Version
140 LOCAL_AI_DISPLAY Local AI Display
141 HF_CABLE HF Cable
142 NSP_VALUE NSP Value
