ALARM_SUM: This parameter summarized the status of
up to 16 block alarms.
4.2 Physical Block
The Physical Block contains data specific to the Enhanced
Model 705 PA transmitter, along with some
information about the firmware.
NOTE: The Physical Block has no control function.
MODE_BLK: Actual mode must be in AUTO in order for
the AI Function blocks in the transmitter to operate.
NOTE: A Physical Block in “out of service” will stop all function block
execution in the transmitter.
SOFTWARE_REVISION: Revision number of the
software of the field device.
HARDWARE_REVISION: Revision number of the
hardware of the field device.
DEVICE_MAN_ID: Identification code of the
manufacturer of the field device.
DEVICE_ID: Manufacturer specific identification of the
device.
DEVICE_SER_NUM: Serial number of the device.
DIAGNOSIS: Detailed information about the device,
bitwise coded.
DIAGNOSIS_EXTENSION: Additional detailed
information about the device.
DIAGNOSIS_MASK: Definition of supported
DIAGNOSIS information-bits.
0 = not supported
1 = supported
DIAGNOSIS_MASK_EXTENSION: Definition of sup-
ported DIAGNOSIS_EXTENSION information-bits.
0 = not supported
1 = supported
DEVICE CERTIFICATION: Pertinent certifications of
the device.
21
57-645 Eclipse Guided Wave Radar Transmitter - PROFIBUS PA
™
