63
57-600 Eclipse
®
Guided Wave Radar Transmitter
7
TT 3
1
⁄2" 600# Fisher
®
- Proprietary Carbon Steel (249B) Torque Tube Flange
T
U 3
1
⁄2"
600# Fisher - Proprietary 316 Stainless Steel (249C) Torque Tube Flange
UT 3
1
⁄2" 600# Masoneilan
®
- Proprietary Carbon Steel Torque Tube Flange
UU 3
1
⁄2" 600# Masoneilan - Proprietary 316 Stainless Steel Torque Tube Flange
PROPRIETARY AND SPECIALTY FLANGE CONNECTIONS
➀ Configuration/Style Codes A, D, P, R & S only
➁ Configuration/Style Codes D & P only
24" to 240" (60 cm to 610 cm) (7xQ and 7xS: 180" (457 cm) maximum)
(unit of measure is determined by second digit of Model Number)
Examples: 24 inches = 024; 60 centimeters = 060
LENGTH – RIGID PROBE MODELS
LENGTH – FLEXIBLE PROBE MODEL
6' to 75' (1 to 22 m)
(unit of measure is determined by second digit of Model Number)
Examples: 30 feet = 030; 10 meters = 010
EA DN 80, PN 16 DIN 2527 Form B Flange
EB DN 80, PN 25/40 DIN 2527 Form B Flange
ED DN 80, PN 64 DIN 2527 Form E Flange ➀
EE DN 80, PN 100 DIN 2527 Form E Flange ➀
EF DN 80, PN 160 DIN 2527 Form E Flange ➁
EG DN 80, PN 250 DIN 2527 Form E Flange ➁
EH DN 80, PN 320 DIN 2527 Form E Flange ➁
EJ DN 80, PN 400 DIN 2527 Form E Flange ➁
FA DN 100, PN 16 DIN 2527 Form B Flange
FB DN 100, PN 25/40 DIN 2527 Form B Flange
FD DN 100, PN 64 DIN 2527 Form E Flange ➀
FE DN 100, PN 100 DIN 2527 Form E Flange ➀
FF DN 100, PN 160 DIN 2527 Form E Flange ➁
FG DN 100, PN 250 DIN 2527 Form E Flange ➁
FH DN 100, PN 320 DIN 2527 Form E Flange ➁
FJ DN 100, PN 400 DIN 2527 Form E Flange ➁
BA DN 25, PN 16 DIN 2527 Form B Flange ➀
BB DN 25, PN 25/40 DIN 2527 Form B Flange ➀
BC DN 25, PN 64/100 DIN 2527 Form E Flange ➀
BF DN 25, PN 160 DIN 2527 Form E Flange ➁
CA DN 40, PN 16 DIN 2527 Form B Flange ➀
CB DN 40, PN 25/40 DIN 2527 Form B Flange ➀
CC DN 40, PN 64/100 DIN 2527 Form E Flange ➀
CF DN 40, PN 160 DIN 2527 Form E Flange ➁
CG DN 40, PN 250 DIN 2527 Form E Flange ➁
CH DN 40, PN 320 DIN 2527 Form E Flange ➁
CJ DN 40, PN 400 DIN 2527 Form E Flange ➁
DA DN 50, PN 16 DIN 2527 Form B Flange
DB DN 50, PN 25/40 DIN 2527 Form B Flange
DD DN 50, PN 64 DIN 2527 Form E Flange ➀
DE DN 50, PN 100 DIN 2527 Form E Flange ➀
DF DN 50, PN 160 DIN 2527 Form E Flange ➁
DG DN 50, PN 250 DIN 2527 Form E Flange ➁
DH DN 50, PN 320 DIN 2527 Form E Flange ➁
DJ DN 50, PN 400 DIN 2527 Form E Flange
DIN FLANGE CONNECTIONS
