BE57-646 ECLIPSE Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
H
ome Screen
M
ain Menu
Device Setup Quick Start
I
dentity
Basic Config
D
isplay Config
Advanced Config
Factory Config
S
ensitivity:
0 to 100 echo strength units
Blocking Distance:
-7.5 to +100 feet
(-2 m to 30 m)
Safety Zone Alarm:
O
ff
On
Latch
Safety Zone Height:
(not used when Safety Alarm is
None)
2 inches to100 feet
(5 cm to 30 m)
Reset SZ Alarm
(used when Safety Alarm is Latch)
Failure Alarm Delay:
0 to5seconds
Level Trim:
-2.00 to + 2.00 feet
(-0.6 mto+0.6m)
THRESHOLD SETTINGS
Lvl Thresh Mode:
Auto Largest
(not used with Interface and Level)
Fixed Value
Auto Upper
Sloped
Sloped Start Value:
(When Lvl Thresh Mode is Sloped)
Lvl Thresh Value:
0 to100 echo strength units
Sloped Start Value
(used when Lvl Thresh Mode is
Sloped)
0 to100 echo strength units
S
loped End Dist:
(used when Lvl Thresh Mode is
S
loped)
25 to 100 feet
(7 to 30 m)
Ifc Lvl Thresh Mode:
(
Interface and Level only)
Auto Largest
F
ixed Value
Ifc Lvl Thresh Value:
(
Interface and Level only)
0 to 100 echo strength units
EoP Thresh Mode:
Auto Largest
Fixed Value
EoP Thresh Value:
0 to 100 echo strength units
ENDofPROBE ANALYSIS:
EoP Polarity:
Positive
Negative
EoP Analysis:
(not used with Interface and Level)
Off
On
EoP Dielectric:
(not used with Interface and Level)
1.20 to 9.99
ECHO REJECTION:
View Echo Curve
View Reject Curve
REJECTION CONTROL:
Reject CurveState:
Off
Disabled
[Enabled]
R
eject CurveMode:
Level
D
istance
Saved Medium
N
EW REJECT CURVE:
Actual Medium
S
ave Reject Curve
Compensation:
N
one
Auto
Manual
Vapor Dielectric
1.00 to 2.00
HF Cable Length:
Integral
3 feet
12 feet
Buildup Detection:
Off
On
New User Password:
0 to59,999
CONFIG CHANGED:
Indicator Mode:
Disabled
Enabled
Reset Config Chngd:
Reset?
No
Yes
Reset Parameters:
No
Yes
4.5 Model 706 Configuration Menu — Device Setup
