11
BE57-646 ECLIPSE Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
BLOCK_ALM (Block Alarm): Is used for configuration,
hardware, connection, or system problems in the block. The
cause of any specific alert is entered in the subcode field.
ALARM_SUM (Alarm Summary): Contains the current
alert status, the unacknowledged states, the unreported
states, and the disabled states of the alarms associated with
the block.
ACK_OPTION (Acknowledge Option): Selects whether
alarms associated with the block will be automatically
acknowledged.
WRITE_PRI (Write Priority): The priority of the alarm
generated by clearing the write lock.
WRITE ALM (Write Alarm): The alert generated if the
write lock parameter is cleared.
ITK_VER (ITK Version): Contains the version of the
Interoperability Test Kit (ITK) used by the Fieldbus
Foundation during their interoperability testing.
COMPATIBILITY_REV: This parameter is intended to
assist users and host system in device replacement scenarios.
It is a read-only parameter and the value of the
COMPATIBILITY_REV is defined by the device developer
and manufacturer. In such device replacement scenario the
DEV_REV value of the replaced device is equal or greater
than the COMPATIBILITY_REV value of the new device.
Additional parameters are available within the resource
block for use with NE-107 to aid in communicating device
conditions to the user.
FD_VER: Major version of the Field Diagnostic specifica-
tion to which this device conforms.
FD_FAIL_ACTIVE: For error conditions that have been
selected for the FAIL alarm category, this parameter reflects
those that have been detected as active.
FD_OFFSPEC_ACTIVE: For error conditions that have
been selected for the OFFSPEC alarm category, this para-
meter reflects those that have been detected as active.
FD_MAINT_ACTIVE: For error conditions that have been
selected for the MAINT alarm category, this parameter
reflects those that have been detected as active.
FD_CHECK_ACTIVE: For error conditions that have
been selected for the CHECK alarm category, this parame-
ter reflects those that have been detected as active.
FD_FAIL_MAP: Maps conditions to be detected as active
for the FAIL alarm category.
