BE57-646 ECLIPSE Guided Wave Radar Transmitter - FOUNDATION fieldbus
™
Refer to the table below for a complete listing of the Model
706 diagnostic indicators, along with their explanations,
default categories, and recommended remedies.
N
OTES: 1) The remedies shown in this table can also be seen on
the transmitter LCD by viewing the present status
screen when the device is in a diagnostic condition.
2) Those indicators showing failure as the default result
in an alarm condition.
The DD and DTM allow for the ability to manipulate
diagnostic indicators mapped to NE-107 alarm categories in
Resource Block. Intended as a means to verify the configu-
ration of the diagnostic parameters and connected equip-
ment, a user can manually change any indicator in the
Resource Block to and from the active state.
Below is a listing of the Model 706 diagnostic indicators,
showing their priority, explanations and recommended
remedies. (Priority 1 is highest priority.)
Software Error
Failure
Unrecoverable error occurred in stored
program.
Contact MAGNETROL
Technical Support.
RAM Error
Failure RAM (read/write) memory failing.
ADC Error
Failure Analog-to-digital converter failure.
EEPROM Error
Failure Non-volatile parameter storage failing.
Analog Board Error
Failure Unrecoverable hardware failure.
Spare Indicator 1
OK Reserved for future use.
Default
Parameters
Saved parameters are set to default
values.
Perform complete Device Configuration.
No Probe
Failure No Probe Connected.
Ensure “Model 706 Style” probe is
attached.
Torque HF nut.
Clean gold pin on transmitter and socket
on probe.
Contact MAGNETROL Technical Support.
No Fiducial
Failure Reference signal too weak to detect.
Torque HF nut.
Clean gold pin on transmitter and socket
on probe.
Check settings:
Fiducial Gain
HF Cable Length
Window
Increase Fid Gain.
Contact MAGNETROLTechnical Support.
