Magnetrol Eclipse 706 - Appendix B: Transducer Block Tables

56
BE57-646 ECLIPSE Guided Wave Radar Transmitter - FOUNDATION fieldbus
  
0 BLOCK_STRUCTURE BLOCK STRUCT
1 ST_REV Static Revision
2 TAG_DESC Tag Description
3 STRATEGY Strategy
4 A
LERT_KEY
A
lert Key
5 MODE_BLK Block Mode
6 BLOCK_ERR Block Error
7 UPDATE_EVT Update Event
8 BLOCK_ALM Block Alarm
9 TRANSDUCER_DIRECTORY Transducer Directory
10 TRANSDUCER_TYPE Transducer Type
11 XD_ERROR Transducer Error
12 COLLECTION_DIRECTORY Collection Directory
13 MEASUREMENT_TYPE Measurement Type
14 LEVEL Level
15 LEVEL_UNIT Level Unit
16 DISTANCE Distance
17 DISTANCE_UNIT Distance Unit
18 PROBE_MODEL Probe Model
19 PROBE_COATING Probe Coating
20 PROBE_MOUNT Probe Mount
21 PROBE_LENGTH Probe Length
22 PROBE_LEVEL_OFFSET Level Offset
23 DIELECTRIC_RANGE Dielectric Range
24 SENSITIVITY Sensitivity
25 BLOCKING_DISTANCE Blocking Distance
26 SAFETY_ZONE_MODE Safety Zone Mode
27 SAFETY_ZONE_HEIGHT Safety Zone Height
28 RESET_SAFETY_ZONE_LATCH Reset SZ Latch
29 ALARM_DELAY Failure Alarm Delay
30 LEVEL_TRIM Level Trim
31 LEVEL_THRESHOLD_MODE Level Threshold Mode
32 LEVEL_THRESHOLD_VALUE Level Threshold Value
33 SLOPED_START_VALUE Sloped Start Value
34 SLOPED_END_DISTANCE Sloped End Distance
Appendix B

