SZHeight
xx.x su
U
ser
 distance below BlockDis where
SZ Fault will be asserted
5.1 to 2286 cm (2 to 900 in)

SZ Latch
Reset
User
 Enter to clear a Safety Zone latch

Threshld
(select)
User
from CFD, Fixed
For interface, refers to threshold for
upper level pulse

Trim Lvl
xx.x su
Superuser or
u
ser
 value to adjust Level reading
-20.0 inches <= Lvl Trim <= +20.0 inches
(Superuser password required if negative
fiducial.)

AI Disp
User
Transmitter Display AI Block Display

LvlTicks
xxxxx
User
Diagnostic Display Time of flight from fiducial to level signal

New Pass
xxx
User
 new password (0-255)
Displays encrypted value of present
password

Language
(select)
User
 from English, Spanish, French,
German
Language choice for
LCD display

Mdl705FF
Ver 3.xx
None
Transmitter Display
Product identification
Firmware version

DispFact
(select)
None
 Yes to display factory parameter
menus

History Status
None
Diagnostic Display to view present status
and recent exceptions

Run Time
xxxx.x h
None
Diagnostic Display showing elapsed
time since power on
Cleared to zero with History Reset

History
Reset
Superuser
 Enter and select yes to clear
history
Reset History Data

HF Cable
Select
Superuser
Select length of remote
extension cable
Select from integral, 3-foot, 12-foot

FidTicks
xxxx
None
Diagnostic Display
Time of flight from start of
ramp to fiducial

Fid Sprd
xxx
None
Diagnostic Display Spread in fiducial ticks readings

Fid Type
(select)
Superuser
Superuser parameter
 from Positive, Negative.
Selection only allowed for some probes,
fixed for others

Fid Gain
xxx
Superuser
Superuser parameter

Window
xxx
Factory
Factory Parameter Calibration parameter

Conv Fct
xxxx
Factory
Factory Parameter Calibration parameter

Scl Ofst
xxx
Factory
Factory Parameter Calibration parameter
